  • MASS-Kobo Model 485

MASS-Kobo Model 485

Balanced Headphone Amplifier

  • Successor to the Model 394 series, the new Model 485 features an updated design with a 4.4mm balanced output, now the industry standard.
  • Balanced XLR inputs support +4dBm/-10dBm, while unbalanced RCA inputs follow the -10dBm standard.
  • Includes an output switch for “Low” (normal-efficiency headphones) and “Hi” (low-efficiency headphones like planars).
  • Equipped with custom conductive plastic faders by Tokyo KO-ON Denpa, typically used in high-end pro audio mixers.
  • It features a high performing, 4 channel TDK potentiometer.
Regular price £5,499.00
Sale price £5,499.00 Regular price
Unit price
Save

VAT Included for UK Customers.

For international customers, VAT is already removed from the displayed price. International Customers will incur local import taxes and duty charges.

VAT and Import Taxes FAQ
    MASS-Kobo Model 485

    MASS-Kobo Model 485

    Regular price £5,499.00
    Sale price £5,499.00 Regular price
    Unit price

    Made in JAPAN - Built to Order

    Successor to the popular Model 394 series; which was discontinued due to the discontinuation of some parts by their manufacturers, the Model 485 will see its design updated to include a 4.4mm balanced output, which has become the standard in recent years.

    Technical Details

    General

    • Balanced input/output stereo headphone amplifier

    Inputs & Outputs

    • XLR3-31 equivalent x 2 (electronically balanced), RCA x 2 (unbalanced)

    • 4.4mm Pentaconn, XLR4-31 (balanced stereo), XLR3-31 (L/R balanced)

    Input Specifications

    • 3.7kΩ (XLR), 12kΩ (RCA)

    • +4dBm / -10dBm (XLR), -10dBm (RCA)

    • +25dBm (XLR), +10dBm (RCA)

    Output Specifications

    • Unbalanced: Hi 12V / Low 9V
      Balanced: Hi 24V / Low 18V
      (32Ω load, 1kHz, THD+N 0.05%)

    • Unbalanced: Hi 4.2V / Low 3V
      Balanced: Hi 8.5V / Low 6V
      (32Ω load, 1kHz, THD+N 0.05%)

    • Balanced: 2.2W+2.2W
      Unbalanced: 600mW+600mW
      (32Ω load, 1kHz, THD+N 0.05%)

    Power & Physical

    • AC 100V–240V, 50Hz/60Hz

    • 0.5A (at AC100V)

    • Without feet: 285 x 230 x 50mm
      With feet: 285 x 258 x 52mm

    • 2.9kg (main unit only)
