Benchmark DAC3 B

Reference professional balanced DAC

  • ESS Technologies ES9028PRO converter chip
  • UltraLock3™ jitter attenuation system
  • Adjustable gain via internal jumpers
  • 5 digital inputs
  • Analogue XLR and RCA outputs
  • Harmonic Compensation
  • Multi-Mode Asynchronous USB Audio System
  • High-Headroom DSP
  • Quad 32-bit balanced D/A Conversion System
  • Distributed Power Regulation
  • Designed, assembled and tested in the USA
Low Stock
Low Stock
Style: New
Regular price
$2,135.00
Regular price
Sale price
$2,135.00
Sale
SHIPS FROM THE UNITED KINGDOM

All our products ship from the UK. UK prices include local VAT. International orders will incur the destination's local taxes and duty charges.

Benchmark DAC3 B

Vendor: Benchmark

Benchmark DAC3 B

$2,135.00

Vendor: Benchmark

Benchmark DAC3 B

$2,135.00
Style: New

Reference Performance

The DAC3  delivers outstanding musical detail and precise stereo imaging. It employs an advanced high-headroom digital filter design, and a high-sample-rate Asynchronous USB Audio interface. All inputs are fully isolated from interface jitter by Benchmark's new UltraLock3™ jitter attenuation system.
Internal digital processing and conversion is 32-bits, and this processing includes 3.5 dB of headroom above 0 dBFS. This headroom prevents the DSP overloads that commonly occur in other D/A converters.
4 balanced 32-bit D/A converters are summed together to create each balanced analogue output. This 4:1 summation provides a 6dB noise reduction and gives the DAC3 industry-leading performance.



Box Contents:

  • DAC3 B
  • IEC power cable
  • USB type A to B data cable
  • User manual & safety instructions


technical specifications
Dimensions
H 45mm, W 249mm, D 216mm
DAC chipset
ESS Technologies ES9028PRO
PCM support
Up to 192kHz
DSD support
Up to DSD64
Digital inputs
USB type B, 2x coaxial RCA, 2x optical TosLink
Analogue output
XLR, RCA
THD+N
-119dBFS, -116dB, 0.00016% (1kHz @ -3dBFS)
Crosstalk
-137dB at 20Hz
Weight
1.36KG
Chassis material
Aircraft grade machined Aluminium
