Silver in stock, ready to ship

Out of stock - Accepts Pre-Orders

In Stock and Ready to Ship

Ships in 1 to 3 business days. Monday to Friday, except bank holidays. Subject to stock availability and security checks.

  • Silver
Out of Stock - Allows Pre-Orders

Message us in discord or our website chat to find out pre-order time.

  • Black

SPL Phonitor SE

The entry into VOLTAiR amplification

  • Up to 5W into 250Ω
  • 2 levels of Crossfeed
  • Smooth Alps RK27 "Big Blue" potentiometer
  • Bottom 12dB gain DIP switch
Silver
Black
Regular price $1,115.00
Sale price $1,115.00 Regular price
Unit price
Save

VAT and Duties Included for UK and Eligible EU Customers.

If you are outside the UK or EU, the price does not include any taxes. Local taxes and import duties will be extra. They will be raised by the local authorities and billed directly to the customer.

VAT and Import Taxes FAQ
SPL Phonitor SE

SPL Phonitor SE

Everything under control

The volume is adjusted with a massive, milled Aluminium, rotary knob. The Alps RK27 “Big Blue” potentiometer gives a pleasant “spoon in the honey” rotary feel.

Unlike the bigger Phonitor models, where the “Angle” switch can be used to select the opening angle of the stereo stage, this parameter is fixed at a default value of 30° for the Phonitor se. The “Crossfeed” parameter can be set in two stages – “C1” and “C2”. “C2” provides higher crosstalk/crossfeed than “C1”.



Headphone Output with Power

The Phonitor se offers a 6.35 mm jack for connecting headphones with jack plug. Up to 2 x 5 watts of output power is available at this socket. This allows even very power-hungry headphones such as planar magnetic to be driven effortlessly.

The 120V technology is our reference technology. The 120V technology is unique in the world. It operates at a DC voltage of 120 volts. This is four times that of IC-based semiconductor op-amps. In our Professional Fidelity series, we refer to this unsurpassed technology as VOLTAiR technology.

Technical specifications

Dimensions
278*57*300mm
Dynamic Range
135.5dB
Amplification
120V VOLTAiR
Output Power
5W@250Ω, 1W@32Ω
Crosstalk (1 kHz, 0 dBu)
-90dB
THD + N (1 kHz, 0 dBu)
0.00091%
Noise (A-weighted)
-103dBu
Maximum input gain
32.5dBu
Damping factor (40 Ω)
180
Source Impedance
0.18Ω
